V type Condenser

Condensers are of reasonable structure, good compatibility and can be matched with various compressors;
The shell is made of quality steel with powder coating, which is corrosion-resistant and beautiful;
The condensers are tested under air pressure 2.875MPa, make sure the products'high gas tightness;
According to customer's requirement, different condenser fans are available.

Inquiry

Overview
Inquiry
Related Products

Power supply: 380V/3PH/50HZ \| Refrigerant: R404A
Fin spacing: 2mm
Model	Δt	YVB502A	YVB503A	YVB504A	YVB552A	YVB553A	YVB554A	YVB552B	YVB552B-D	YVB553B	YVB554B
Capacity (kw)	15K	57.0	84.6	113.9	69.6	107.5	139.1	85.1	76.6	125.2	170.3
	12K	45.6	67.8	91.3	55.7	86.1	111.5	68.2	61.4	100.3	136.5
	10K	39.1	58.1	78.2	47.8	73.8	95.5	58.5	52.6	85.9	116.9
Air volume	m³/h	14600	21900	29200	20400	30600	40800	19600	19600	29400	39200
Common Data
Fan qty	NO.	2-φ500	3-φ500	4-φ500	2-φ550	3-φ550	4-φ550	2-φ550	2-φ550	3-φ550	4-φ550
Fan power	Kw	1.01	1.52	2.02	1.5	2.25	3	1.5	1.5	2.25	3
Fan current	A	2.2	3.3	4.4	3.5	5.25	7	3.5	3.5	5.25	7
Noise	dB	72	72	72	73	73	73	73	73	73	73
Tube volume	dm³	3.83	5.74	7.65	4.57	6.86	9.15	6.10	6.10	9.15	12.2
Connection	φmm	19/28	22/28	25/35	22/28	22/28	25/35	22/28	22/28	25/35	32/42
Weight	Kg	214	269	323	241	317	395	252	252	334	418
Dimensions	A	1560	2210	2860	1620	2300	2980	1620	1620	2300	2980
	B	890	890	890	980	980	980	980	980	980	980
	C	1850	1850	1850	1940	1940	1940	1940	1820	1940	1940
Notes: Capacity based on ambient temperature 32°C, humidity 50%, subcooling 5°C.
